Non-Pressure Tubes Solar Water Heaters

Rongchang Non-Pressurized Solar Water Heater:

This type uses the all glass evacuated solar collector tubes as the heat-absorbing element. The high vacuum degree of the clearance between the outer and inner tube reduces the heat emission which is caused by convection and conduction.The layer films(coating) of the all glass evacuated tubes transfer the sun energy into heat energy. The high absorption and low emittance rate of Rongchang's layer fils is unique. Depending on the different density between hot water and cold water, a water flowing cycle is created in the tube. Hot water flows automatically upwards while the cold water flows downward. The water in the storage tank will be heated from this natural circulation.

Non Pressurized Tubes Solar Heaters - Key Specification:

1)inner tank: stainless steel SUS304-0.5mm

2)vacuum tube: AL-N/AL/58-1800

3)outer tank: Galvanized steel-0.4mm

4)frame:galvanized steel-1.5mm

5)insulation:Polyurethane

6)reflector:aluminum

Important Remarks of this heaters:

Solar heat storage tank diameter(mm):360/460

Thickness,insulated(mm):50

Vent connection(inch):3/4

Electrical heater connection(inch):1

Water connection(inch):3/4

Collector angle(degree):20/45

Please for further information contact us; we will be please to support you within 24 hours and provide you more information of this product or quotation: sales-solar@rongchang-group.com
